Albedo Ether10.DuaLoop

Ether10.DuaLoop is a portable device that loops back traffic on interfaces up to 10 Gbit/s throughput. The device features dual electrical/optical ports that can operate independently in L1-L4 loopback mode. It loops back Ethernet/IP packets, enabling performance tests such as RFC2544 and eSAM (Y.1564). The optical interfaces of the device are provided through SFP+ adapters.

Loopback device up to 10GbE
L1/L2/L3/L4 loopback
Dual SFP/SFP+ and RJ-45 ports
Touchscreen
Battery power

The Ether10.DuaLoop from ALBEDO Telecom (Barcelona) is a battery-powered loopback device for Ethernet/IP networks with throughput up to 10 Gb/s. It loops back test traffic at layers L1-L4 on two independent optical/electrical ports, so full bidirectional RFC 2544 and eSAM (Y.1564) tests can be performed with a single tester and a single measurement team — without sending a second crew to the far end of the link.

Applications

Acceptance and commissioning tests of 1G/10G carrier links — remote loopback end for RFC 2544 and Y.1564 (eSAM) tests
Maintenance and SLA — selective loopback of a chosen service stream (up to 8 filters: MAC, VLAN, MPLS, IPv4/IPv6, UDP)
Testing of two links or two services simultaneously — independent operation of ports A and B
Traffic monitoring in pass-through mode (Ethernet/IP statistics, top talkers)
Field operation — battery power, IP54 enclosure

Key parameters

Parameter	Value
Parameter	Value
Ports	2 × SFP/SFP+ and 2 × RJ-45, operating independently
Throughputs	10 Mb/s – 10 Gb/s (including 10GBASE-SR/LR/ER, 1000BASE-T/SX/LX, 100BASE-TX)
Loopback modes	L1 (bit), L2 (MAC address swap), L3 (IP address swap), L4 (port swap)
Traffic filtering	up to 8 simultaneous filters: Ethernet fields, MPLS, IPv4/IPv6, TCP/UDP + generic filter (16-bit mask)
Internal clock	< ±3.0 ppm
Battery power	LiPO, 8–24 h of operation; 4 h charging
Operation	TFT touchscreen 480×272; remote access via VNC, SNMP; report export via USB
Dimensions and weight	223 × 144 × 65 mm, 1 kg; IP54; operation -10…+50 °C

An intelligent loopback, not just a mirror

Unlike simple hardware loopbacks, the Ether10.DuaLoop loops traffic back selectively: filters allow only the frames of a specific service to be returned (e.g. a single VLAN or UDP stream), while control mechanisms exclude broadcast traffic and ICMP from the loop, protecting the production network against a packet storm. At layers L2-L4 the device swaps source and destination addresses, so the returned traffic correctly travels back through the routed network. In parallel, DuaLoop collects full frame and bandwidth statistics per port, direction and filter — from FCS counters to frame length distribution — and identifies the 25 most active MAC/IPv4/IPv6 addresses (top talkers).

Interlab is an authorized distributor — we provide technical consulting, deployment support and service. Ask for a quote.
