ToupTek TAFDM41X – all-in-one autofocus microscope with 13.3″ touchscreen (4K)

Name: ToupTek TAFDM41X – all-in-one autofocus microscope with 13.3″ touchscreen (4K)
Brand: ToupTek
SKU: 17965

ToupTek TAFDM41X is an integrated all-in-one autofocus microscope with a 13.3″ touchscreen and 4K support (4K@30). It combines motorized continuous zoom (18×/20×), autofocus and an intuitive touch interface (or mouse) – ideal for demonstrations, training and demanding inspection without a computer.

An autofocus camera/microscope automatically focuses on the selected area of the scene, and combined with depth stacking it delivers a sharp image even at high magnification and on an uneven sample. The built-in XCamView interface lets you operate the camera directly on an HDMI monitor (USB mouse), without a computer; the ToupView/ToupLite software extends operation to a PC.

What is an autofocus microscope with a touchscreen?

Key features

Integrated 13.3″ touchscreen (touch/mouse)
Motorized continuous zoom: TAFDM411 20× / TAFDM412 18×
Autofocus (auto / single / manual), adjustable AF area
Sony IMX415 sensor, 4K@30 output HDMI1.4/USB Video/Ethernet/Wi-Fi
XCamView (measurements, auto-edge, stacking, stitching), SD/USB recording, H.264/H.265
Magnetic LED ring controlled from the camera; multilingual menu

Technical specifications

Type	all-in-one autofocus microscope (touch)
Screen	13.3″ touchscreen 1080P
Sensor	Sony IMX415 (1/2.8″)
Zoom	20× (TAFDM411) / 18× (TAFDM412)
Resolution	8 MP, 4K@30
Output	HDMI1.4 / USB Video / Ethernet / Wi-Fi
Working distance	192 mm (411) / 250 mm (412)
Software	XCamView; ToupView/ToupLite

Applications

Teaching and training
Live demonstrations
High-end inspection
Automation integration

Request a quote and configuration

We match ToupTek autofocus cameras and digital microscopes to your application (sensor, zoom/lens, interface, illumination). Contact Interlab to receive a quote and model selection.
