ToupTek X7FCAM4K – 16 MP autofocus camera with Canon EF mount (4K)

Name: ToupTek X7FCAM4K – 16 MP autofocus camera with Canon EF mount (4K)
Brand: ToupTek
SKU: 17962

ToupTek X7FCAM4K (16MPA_EFL) is a 16 MP autofocus camera with a Canon EF mount: once an EF lens is attached, the camera reads the focal length/aperture/focus and controls the aperture as well as AF/MF. The large-format Sony IMX283 sensor and HDMI/USB3.0/Ethernet outputs make it a tool for medical imaging (ophthalmology, dentistry) and UHD inspection.

An autofocus camera/microscope automatically focuses on the selected area of the scene, and combined with depth stacking it delivers a sharp image even at high magnification and on an uneven sample. The built-in XCamView interface lets you operate the camera directly on an HDMI monitor (USB mouse), without a computer; the ToupView/ToupLite software extends operation to a PC.

Why a camera with a Canon EF mount?

Key features

Sony IMX283 sensor, 16 MP (1/1.1″)
Canon EF mount – aperture control, AF/MF, lens readout
4K HDMI / USB3.0 / Ethernet output (parallel)
Depth stacking + lens distortion correction
RAW, voice control, network upload
XCamView (measurements, auto-edge); ToupView/ToupLite, app

Technical specifications

Type	16 MP autofocus camera, EF mount
Sensor	Sony IMX283, 16 MP (1/1.1″)
Mount	Canon EF (AF/MF, aperture)
Output	HDMI / USB3.0 / Ethernet, 4K@30
Functions	depth stacking, distortion correction, RAW, voice
Software	XCamView; ToupView/ToupLite

Applications

Ophthalmology and dentistry
UHD industrial inspection
Precision assembly
Scientific research

Request a quote and configuration

We match ToupTek autofocus cameras and digital microscopes to your application (sensor, zoom/lens, interface, illumination). Contact Interlab to receive a quote and model selection.
