Home » Products » Research & Scientific Instruments » Eye Tracking » Mobile (Glasses) » Tobii Glasses X

Tobii Glasses X — Eye tracking glasses for research in the field — no calibration

Lightweight glasses with a camera that records what the participant sees, and cameras that track their eyes. The recording shows where they were looking at every moment — at a machine, at a store shelf, behind the wheel. Put them on, connect to a phone and record.

Request a quote Technical specifications

120Hzgaze sampling rate

72gglasses with cable

132°scene camera angle (diagonal)

QHDscene video 2560×1440, 30 fps

Mechanic wearing Tobii Glasses X tightening a valve on a hydraulic machine

REC · scene camera + gaze 120 Hz

no calibration

What Glasses X are

A camera on the world, cameras on the eyes

An eye tracker measures where a person is looking. In Glasses X, a camera above the nose films what is in front of the participant, and two small cameras inside the frame observe the eyes in infrared light. From the position of the pupil and the light reflection on the eye, the algorithm calculates the gaze direction — and maps it as a point onto the video of the surroundings.

Tobii Glasses X — front view: black frame, scene camera on the bridge above the nose, nose pad below the bridge

1
Scene cameraOn the bridge above the nose. It films what is in front of the participant: 2560 × 1440 pixels, 30 fps, 118° horizontal and 67° vertical angle.
2
Eye cameras and infraredOne camera for each eye and 18 infrared LEDs (9 per eye) along the inner edge of the frame. The light is invisible to the participant.
3
Nose pad with coverKeeps the glasses on the nose; an additional cover improves the fit.
+
Stereo microphones and head motion sensorsAmbient sound (48 kHz) plus a gyroscope, accelerometer and magnetometer — you know how the head moved.
+
USB-C cable to the phone1.2 m; the cable carries data and power for the glasses. The whole unit with the cable weighs 72 g.

No calibration

The participant does not have to look at calibration points. They put on the glasses and the study can begin — this shortens preparation in a factory hall, a store or on the court.

Fixed geometry

The eye cameras and the scene camera are rigidly mounted relative to each other, so the eye position can be translated directly into a point in the scene image.

The glasses may slip

The manufacturer uses a three-dimensional eye model that compensates for the glasses shifting on the nose during movement. Pupil size is measured in absolute values.

One recording — five synchronized tracks

The app records everything on a common timeline. That is why at any moment of the recording you can see at the same time: what was in front of the participant, where they looked, how the pupil changed and how they moved their head.

Scene video2560 × 1440 · 30 fps

Gaze point120 samples per second

Pupil diameterabsolute value

Head movementgyroscope · accelerometer · magnetometer

Audiostereo · 48 kHz

Illustrative waveforms generated in the browser — not a recording from the device. Recorded data: Tobii Glasses X specification.

See · Understand · Improve

From putting on the glasses to team insights

Glasses X were designed for research outside the lab: at the production line, in a store, in a car. That is why the whole system is the glasses, a phone and cloud software — with no separate recording unit and no computer next to the participant.

Worker in a hard hat adjusting Tobii Glasses X on her nose before recording in a production hall

Glasses X scene camera view in a car: the road ahead of the driver and red gaze points connected by a path

Glasses Explore on a laptop: driving recording, timeline and tag library with marked moments

Insight sharing window in Glasses Explore — the “Driving insights” recording being sent to several team members

Start · no calibration

Live · also remotely

Glasses Explore · tags and comparisons

Share · the whole team

Photos and order of steps: Tobii (“See · Understand · Improve”). App description according to Tobii Connect.

Software · Glasses Explore and Tobii Pro Lab

Quick insights or full analysis

The glasses deliver recordings, and the software turns them into knowledge. Glasses X have two levels: Glasses Explore — included, for quick review and sharing insights — and Tobii Pro Lab, when you need numbers, areas of interest and raw data.

Included · one-year license · up to 3 glasses

Glasses Explore

Cloud software designed for Glasses X. Recordings appear in it automatically from the phone.

live view of the camera image and gaze from active glasses
side-by-side comparison of recordings: differences in focus, timing and behavior
tagging key moments and finding recurring patterns
a shared space for sharing results with the team

Data: visual insights, no access to raw data.

Additional license · perpetual or subscription

Tobii Pro Lab

Tobii's research software for eye tracking analysis. You import the recording from Glasses Explore into Pro Lab and calculate metrics.

areas of interest (AOI) and heat maps
advanced behavior coding on the recording
custom metrics tailored to your research question
raw data export for further statistics

Data: raw data export, configurable metrics.

App: Tobii Glasses X for Android (Google Play) Cloud: AES-256 encryption, TLS 1.2+ transmission, Auth0 sign-in, role-based access More about Glasses Explore More about Tobii Pro Lab

Why Glasses X with Interlab

Glasses and software from one manufacturer

Subscription platforms to which you connect glasses from other companies are popular. Glasses X take a different approach: the glasses, the app and the analysis software come from Tobii and work together from day one — and we help you put them into use.

Tobii Glasses X from Interlab compared with a subscription platform and glasses from other manufacturers
Feature	Tobii Glasses X from Interlab	Subscription platform + competing glasses
Analysis software	Glasses Explore included — one-year license, up to 3 glasses	mandatory core module + separately purchased glasses module
Advanced analysis license	Tobii Pro Lab — perpetual or subscription	annual renewal
Glasses and software	one manufacturer — Tobii; recordings go from the phone straight to Glasses Explore	software from one company, glasses from other manufacturers

Platform: a popular multimodal platform with an eye tracking glasses module. Data from manufacturers' websites, as of October 2026.

What you get from Interlab

Test the glasses where they will be used

Field research depends on the location: lighting, movement, people. That is why we start with a test at your site, and after the purchase we stay with your team.

Book a Glasses X demo Request a quote

Test in your environmentA demo or trial loan — try the glasses in a factory hall, a store or a car before you buy.
Model selectionGlasses X or Pro Glasses 3? We advise based on your research question and the accuracy you need.
Authorized Tobii partnerOfficial sales channel: manufacturer's warranty, Glasses Explore and Tobii Pro Lab licenses.
Setup and trainingWe set up the kit and teach your team to record, tag and analyze — in Explore and in Pro Lab.
Methodological adviceWe help you plan field research: tasks, participants, comparisons, metrics.
Help with grants and tendersTechnical descriptions and justifications for applications and tender specifications.
Local support in PolandTechnical and methodological support after the purchase — no intermediaries.
Multimodal labWhen your project grows to include EEG and physiology: Tobii Pro Glasses 3 and BIOPAC from a single supplier.

Accuracy without calibration

What 1.5–2.5° means in practice

Eye tracker accuracy is given in degrees of visual angle, because the error grows with distance from the eye. Without calibration, Glasses X have an accuracy of 1.5–2.5° — the manufacturer classifies it as “enterprise” grade, for use in companies and training. See how large this margin is at different distances.

Man wearing Tobii Glasses X reading a package label at a supermarket shelf

± 4.4 cm the possible offset of the gaze point at 1 m and 2.5°

Enough to show which product on the shelf the customer looked at and how much time they spent on it.

When a single word on a label or a small interface element matters, higher accuracy is needed: Tobii Pro Glasses 3 — 0.6° after one-point calibration.

Accuracy: tobii.com (product page and model comparison). Offsets calculated as distance × tan 2.5°; circles on the photo are illustrative.

Applications

Wherever attention determines the outcome

The manufacturer designed Glasses X for training and skills transfer, quality improvement in production, workflow analysis, consumer research, human factors, engineering, education and healthcare.

Mechanic wearing Tobii Glasses X working on an engine on a car assembly line

Training and quality control

A recording of an experienced worker shows what they look at during assembly or inspection — knowledge that is hard to put into words. New employees learn from their example, and the trainer sees where they need support.

2 weeks → 3 daysvisual inspector training at Pigeon (with Tobii glasses)halfthe training time for new employees at Denso (with Tobii glasses)

Customer wearing Tobii Glasses X comparing two packages in a drugstore

Consumer research

Packaging, shelf, displays and the customer's path through the store — from the shopper's perspective.

Nurse wearing Tobii Glasses X operating an infusion pump next to an IV stand

Healthcare

Operating medical devices in simulated clinical scenarios — where staff look, hesitate and make mistakes.

Pilot wearing Tobii Glasses X and a headset in an aircraft cockpit, with instrument displays in front of her

Human factors and engineering

Cockpits, control rooms, machine panels: which indicators the operator checks and which they skip.

Driver wearing Tobii Glasses X driving a car in city traffic

Drivers and UX

Driver training, use of in-car interfaces and devices — where friction appears.

Tennis player wearing Tobii Glasses X waiting for a serve on the court

Sports

On the field and in training: how an athlete reads the game and reacts.

Photos: Tobii. Training results according to customer stories on the Tobii Glasses X page.

Two Tobii glasses models

Glasses X or Tobii Pro Glasses 3?

They are not successor and predecessor, but two models for different tasks, offered side by side. Glasses X focus on simplicity and fast deployment, Pro Glasses 3 — on the accuracy and control of scientific research.

Two pairs of Tobii glasses side by side: on the left Tobii Pro Glasses 3 with visible LEDs on the lenses, on the right Tobii Glasses X

Tobii Pro Glasses 3Tobii Glasses X

Choose Tobii Pro Glasses 3 when:

you need scientific-grade accuracy (0.6° after calibration)
you combine eye tracking with EEG, physiology or motion capture
you synchronize devices in hardware via a TTL port
you run clinical, neuroscience or precision UX research

Choose Tobii Glasses X when:

you want to start recording right away, without calibration
you train employees and improve procedures or quality
you run consumer and UX research in the field
your team needs to watch recordings live and together in the cloud

Tobii Pro Glasses 3 and Tobii Glasses X according to the manufacturer's comparison
Feature	Tobii Pro Glasses 3	Tobii Glasses X
Calibration	required for precision (one-point)	not needed
Accuracy	0.6° — “scientific” grade	2.5° without calibration — “enterprise” grade
Eye cameras	two per eye	one per eye
Sampling rate	50–100 Hz (depending on mode)	120 Hz
Scene camera angle	95° × 63° (106° diagonal)	118° × 67° (132° diagonal); image stabilization
Data recording	recording unit, memory card	Android app, Glasses Explore cloud
Multimodal research	full integration with EEG, biosignals, motion capture; TTL port	basic sensor data; no TTL port
Software	Tobii Pro Lab	Glasses Explore or Tobii Pro Lab
Weight with cable · audio	76.5 g · mono microphone	72 g · stereo microphones
Corrective lenses	from −8 to +3 diopters	from −6 to +3 diopters

Source: tobii.com, “Tobii Glasses X vs Tobii Pro Glasses 3” (as of October 2026).

Specifications

Technical specifications

According to the manufacturer's current specification.

Tobii Glasses X — eye tracking glasses, front view

Tobii Glasses X technical specifications
Parameter	Value
Eye tracking
Method	pupil center corneal reflection (PCCR), dark pupil; binocular
Sampling rate	120 Hz
Calibration	not required
Accuracy	1.5–2.5°without calibration; the Tobii model comparison lists 2.5°
Slippage compensation	yes — three-dimensional eye model
Pupil measurement	yes — absolute value
Eye cameras · illumination	2 (one per eye) · 18 infrared LEDs (9 per eye)fixed system geometry
Scene camera and audio
Video resolution	2560 × 1440 pixels, 30 fps; H.264 in an MP4 file
Fields of view	118° horizontal, 67° vertical, 132° diagonal
Image stabilization	yes; HD resolution after stabilization
Audio	built-in stereo microphones; 16 bit, 48 kHz, AAC 128 kbit
Motion sensors	gyroscope, accelerometer, magnetometer
Glasses
Weight	72 g (glasses 56 g + cable 16 g)
Frame dimensions	156 × 163 × 49 mm (W × D × H)
Material	carbon fiber reinforced Grilamid (PA12) and stainless steel; nose pad with cover
Corrective lenses	from −6 to +3 diopters (corrective lens kit)
Cable and power	1200 mm, USB-C; powered via USB-C (5.5 V DC, max. 0.5 A)
Recording and software
Recording	Tobii Glasses X app on a compatible Android phonerecording also without Wi-Fi or cellular network; automatic upload to the cloud
Analysis	Glasses Explore (included: one-year license, up to 3 glasses) · Tobii Pro Lab (perpetual or subscription license)
External synchronization	no TTL port
Data protection	AES-256, TLS 1.2 or later, keys in AWS KMS; Auth0 authentication, role-based access

Tobii Glasses X with corrective lenses attached, front view

Corrective lens kit

For participants with vision impairment: from −6 to +3 diopters, attached to the glasses.

Sunglasses clip-on

For outdoor recordings in strong sunlight.

Source: tobii.com, Tobii Glasses X product page and Tobii Connect (as of October 2026).

Frequently asked questions

Do the glasses need to be calibrated before recording?

No. The participant puts on the glasses, and recording starts from the app on the phone. The trade-off for no calibration is an accuracy of 1.5–2.5° — enough to determine which object or area the participant is looking at. For measurements requiring 0.6°, there is Tobii Pro Glasses 3.

Is an internet connection needed during recording?

No. The app also records when the phone is disconnected from Wi-Fi and the cellular network. Data is stored temporarily on the phone and uploaded to the cloud automatically. Remote live view, of course, requires a connection.

Can people who wear prescription glasses take part in studies with them?

Yes — with the corrective lens kit from −6 to +3 diopters, attached to Glasses X. For work in the sun there is a sunglasses clip-on.

Will I get raw data for statistics?

Not in Glasses Explore: it is a tool for visual insights, tagging and comparisons. Raw data, areas of interest, heat maps and custom metrics are provided by Tobii Pro Lab, into which you import recordings from Glasses Explore.

Can Glasses X be connected to EEG or physiological measurement?

No — Glasses X do not work with BIOPAC systems and have no TTL synchronization port; the manufacturer describes their integration as basic sensor data. For multimodal research we offer Tobii Pro Glasses 3 with a BIOPAC system — we will put together the configuration. Tell us about your study.

What is included?

Tobii Glasses X, a one-year Glasses Explore license (up to three glasses), access to storage and features in the cloud, plus support and training materials from the manufacturer. We will confirm the list of compatible Android phones and the Tobii Pro Lab license in our quote.

Where are the recordings stored?

In the manufacturer's cloud: data is stored with AES-256 encryption, transmitted with TLS 1.2 or later, and keys are managed in AWS Key Management Services. Sign-in is provided by Auth0, with role-based access control.
