AEM TestPro & LANTEK IV – Certification Tester Rental

Certification of CAT5e, CAT6, CAT6A, CAT7, CAT7A, CAT 8.1, CAT8.2 level IIG cabling

TestPro supports testing and certification for network deployments up to
40 Gigabit Ethernet for Cat 5e, 6, 6A, 7, 8 or Class I / II cabling systems. The measurement connectors deliver the Level 2G/VI accuracy required for Cat 8 / Class I/II testing, exceeding current measurement requirements for the 2,000 MHz frequency and providing measurement capability up to 3000 MHz. As a result, you can be confident in the measurement results across the full measurement frequency range.

Single-mode and multimode fiber certification

An integrated voltmeter verifies the correctness of hybrid-powered fiber
An integrated visual fault locator (VFL) identifies breaks in the link

Verify PoE

TestPro stands out with PoE validation thanks to a comprehensive set of test functions, including RealPower load testing , with support for 802.3 af / at / bt, UPoE

Qualify Multi-Gigabit link performance up to 10GigE

Using signal-to-noise ratio (SNR) measurement both under traffic load and PoE, if PSE is present, you can check detailed link speed information for each pair and the available margin

Verify connectivity to wired and wireless networks

Detailed network troubleshooting capabilities by checking switch-related details, ping, traceroute, signal strength functions and much more.

Tester advantages
– Copper cable certification testing – TestPro CV100 features an advanced RF measurement engine capable of handling a frequency range up to 3GHz. TestPro supports all mode combination parameters (including TCL) and exceeds Level 2G accuracy specifications for copper certification tests.
– Single Pair Ethernet (SPE) – TestPro supports SPE cable testing using interchangeable test adapters
– Fiber network certification – TestPro fiber measurements provide Tier-1 certification in accordance with industry standards, along with configurable limits for multimode and single-mode fiber cabling. In addition, these adapters include an integrated VFL for a quick indication of a break in the cable, as well as an integrated connection port for measuring electrical voltage in hybrid-powered fiber applications, supporting solutions used in smart buildings.
– Connector cleanliness inspection – Dirty connectors are the most common cause of poor fiber link performance. The TestPro connector inspection function lets you check the cleanliness of fiber endfaces both in the installation environment and during troubleshooting.
– Scalability and flexibility – TestPro 100 ships with optional detachable adapters that enable a wide range of test functions to meet the needs of today’s network infrastructure, while also scaling easily to meet future requirements.
– Autotest function – Autotest is the easiest way to make sure cabling links will support the desired network speed. It is also very fast – in 6 seconds, all parameters required by the standards are checked, plus optional test parameters such as TCL, ELTCL, DC resistance unbalance and others.
– PoE testing – the AD-NET-CABLE adapter provides comprehensive testing to verify PoE deployments. It supports all PoE standards, including 802.3 af / at / bt and UPOE, for reporting PSE configuration and full-load tests with current / power / voltage reporting. In addition, it also allows continuous PoE load tests over extended periods to identify hard-to-find intermittent power drops caused by external loads.
– Multi-gig link speed qualification – TestPro is able to verify a link to make sure Ethernet can be supported at 1/2/5/5 / 10GBASE-T. It can perform SNR measurements under traffic and PoE load, providing confidence that the cabling link will support the desired network speed.
– Network connectivity testing – TestPro can connect to an active Ethernet network via a 10/100/1000 network interface connector or via WiFi (Edimax EW-7822ULC Wi-Fi USB adapter required). Once connected, TestPro automatically detects connected devices on the network. You can ping any other device to verify connectivity and perform traceroute tests and measure latency.
– Wi-Fi testing – TestPro can automatically detect all 2.4 GHz and 5 GHz Wi-Fi SSIDs and their associated RSSI values (received signal power level). This is helpful for detecting Wi-Fi “dead zones” and checking Wi-Fi connectivity using the optional Edimax EW-7822ULC Wi-Fi USB adapter.
– Best-in-industry warranty – all TestPro CV100 units come with a full 2-year warranty from the date of purchase – twice as long as the competition, as proof of our confidence in the quality and reliability of our instruments.
