NorthLab PROCLEAVE LD

A precision fiber cleaver designed for fibers with a diameter of 125-550 µm.

Automated cleaving process for optimal cleave quality and repeatability
Universal fiber clamping mechanism
Designed for fiber diameters from 125 to 550
Low cleave angles with very flat end faces, typically <0.5°
Can be powered by battery or external power supply

The ProCleave LD II is an automatic and highly advanced cleaver for large-diameter fibers up to 550 μm. The cleaver has been specially designed for use on production lines, where ease of use, process speed and high production throughput are critical. At the same time, the cleaver is well suited to R&D environments.

The ProCleave LD II generates very flat end faces and low cleave angles (typically <0.5°) with high repeatability.

To achieve optimal cleave performance and consistency, all key parameters are automatically monitored and controlled.

The ProCleave LD II features a unique and universal clamping mechanism that self-adjusts to the diameter of the fiber used; no external parts or accessories are required.

The ProCleave LD II can be programmed with four different cleave programs, which can be easily selected via the touch panel.

The ProCleave LD II is powered by an external power source or a built-in battery.

Key features

Automated cleaving process for optimal cleave quality and repeatability
Universal fiber clamping mechanism
Designed for fiber diameters from 125 to 550
Low cleave angles with very flat end faces, typically <0.5°
Can be powered by battery or external power supply
Available platforms supporting Fujikura, Fitel, 3SAE or without fiber holders

Technical specification

Dimensions: 150(W) x 90(D) x 60(H) mm, 150(W) x 90(D) x 80(H) mm (including lever)
Weight: 1.1 kg
Power source: Built-in lithium-ion battery or external power supply (100 – 240 V AC, 50/60 Hz)
Supported fibers: from 125 to 550 μm
Supported fiber coating: from 250 to 900 μm
